Green bit dactyscan84c Biometric Devices - Green Bit

Green Bit DactyScan84c-

The Green Bit DactyScan84c is a large-platen optical live fingerprint reader. The reader can catch 4-slap and 2-thumb fingerprints, allowing the 4+4+2 technique to obtain all 10 fingerprints. The DactyScan84c also has the ability to record single-rolled and flat fingerprints.

FBI IAFIS IQS CJIS-RS-0010 (V7) Appendix F compliance has been certified for Green Bit DactyScan84c. It also meets the requirements of ANSI/NIST-ITL-1-2007, ANSI/NIST-ITL-1-2000, and ISO/IEC 19794-4.

Bioscan10 is a compact 4-slap scanner in full compliance with the 10-print capture scanner & software user group requirements suitable for all applications in need of 10 fingerprints flat and rolled acquisition. main applications are visa issuing, e-id documents and criminal identification.

BioScan10 is alive fingerprint scanner, in conformance with international standards, for acquiring 4-slap/2-thumbs fingerprints as well as rolled fingerprints. Its small footprint and low weight increase mobility thus rendering BioScan10 suitable for desktop applications as well as for integrated solutions.

An ergonomic design combined with an easy-to-integrate SDK architecture turning BioScan10 into the perfect choice for integrators and solution providers. BioScan10 integrates a 12 LED graphical user interface eliminating the necessity for skilled operators thus increasing workflow efficiency. No silicon pad or heated glass platen is used resulting high reliability and low maintenance costs.

BioScan10 is suitable for all applications that requiring 4-slapfingerprint acquisition including rolled fingerprints according to FBI IAFIS-IQS quality. BioScan10 processes fingerprints faster, simpler and thanks to Green Bit unique software features more reliable compared to the traditional ink method eliminating the need for skilled operators.

This revolutionary product represents a new age in digital fingerprinting. All civil and law enforcement applications requiring the acquisition of 10-prints will be fully satisfied by BioScan10 performance and quality.

DactyScan84c is a high-speed FBI APP. F certified 10-print Live Scan fingerprint capture device, ideal for large government programs such as E-Passports, border crossing cards, E-ID employee credentials, criminal identification, and all other applications in need of 10 fingerprints captured via 4-slap and rolled acquisition. The DactyScan84c is designed for rapid image acquisition, efficiency and reliability. Its compact size and light weight make DactyScan84c suitable for both desktop applications and integrated mobile ID solutions, including the GIERS (Government Identity Enrollment Station) and PIK (Portable Identity Kit).

Designed for High Security Identity Enrollment and Verification

The DactyScan84c from Greenbit is an FBI APP. F certified 10-print Live Scan fingerprint scanner, ideal for large government programs such as E-Passports, border crossing cards, E-ID employee credentials, criminal identification, and all other applications in need of 10 fingerprints captured via 4-slap and rolled acquisition, according to FBI IAFIS-IQS format requirements. The DactyScan84c meets FBI IAFIS requirements, allowing its fingerprint data to be used for vetting and federal background checks in the United States. The device also meets ANSI/NIST-ITL 2000 & 2007 requirements.

For the highest security, load your fingerprint data onto a CardLogix smart card, like the M.O.S.T Card® or Credentsys® Card, for applications that require multi-factor authentication and secure data storage.

Rapid Fingerprint Capture

The DactyScan84c is the fastest 10-print Live Scan in the market. With up to 27 frames per second for rolled prints acquisition and 25 frames per second for 4 finger slap acquisition, the DactyScan84c is truly unique in terms of acquisition speed. An intuitive user interface facilitates the acquisition process by providing 12 LED light indicators that illuminate correct fingerprint placement, thereby accelerating workflow speed. The device has an optional start and stop feature that senses finger placement for automatic acquisition with quality threshold settings, further speeding up the process.

High Security and Reliability

The DactyScan82c combines high speed acquisition with advanced security and quality utilities, thanks to the easy-to-integrate Multiscan SDK. Features include a dynamic estimation of fingerprint image quality during the scanning process (NISTIR7151 quality check); a correct position and slap completeness check, which checks for correct finger placement and for incomplete slaps due to missing fingers; and slide detection for flat prints, which detects deformations of fingerprints due to sliding during acquisition. Other features include an Anti-Fake "Lite", which distinguishes between real human finger patterns and other surfaces with relief structure, like gloves or tissue, and a finger allocation check, which ensures the presence of a finger core and basic distal flows.

Seamless Data Enrollment and Smart Card Personalization

The DactyScan84c is supported by Raven™ Biometric Enrollment Software from Corvus Integration for all biometric enrollment and matching capabilities. The data is seamlessly transferred from Raven software to the Card Encoding Engine™ Card Personalization Software for immediate in-line chip encoding onto a smart card. Combining smart card technology with biometrics provides the strongest verification and authentication of the cardholder's identity while protecting the privacy and integrity of biometric data.

Seamlessly transfer your biometric data to the Card Encoding Engine™ from CardLogix for the fastest and easiest in-line personalization of smart cards - no programming required. Learn More Here (future whitepaper)

Advanced Features for Better Cost and Time Efficiency

The DactyScan82c combines high reliability with advanced cost-saving for a powerful, reliable and efficient biometric device. Most fingerprint scanners in the market today rely on silicon pads/coating or a heated platen to overcome image quality issues caused by halo or skin conditions. These materials are costly and require regular maintenance. The DactyScan eliminates these maintenance costs and increases image quality reliability by using a more sophisticated solution for halo or skin conditions. In addition, the 12 LED fingerprint location indicators remove the need for skilled operators which saves on labor costs. Coupled with the Multiscan SDK, the DactyScan82c is the perfect choice for a 10-Print Livescan fingerprint scanner.

Lightweight and Compact Design

Its low footprint, light weight (1.4 g/3 lbs) and small size (148 x 152 x 148mm/ 5.8" x 6.0" x 5.8") make DactyScan84c suitable for both desktop applications and integrated mobile ID solutions, including the GIERS (Government Identity Enrollment Station) and PIK (Portable Identity Kit) powered by Raven™ Biometric Enrollment Software.
